Full made-to-order Delivery date: Please contact us
Size:220x220x95 Weight: 2.4kg (excluding external power supply) Input terminal: Phono x2(RCA), LINE x2(RCA), IN x1(6.3mm Phone) Output terminals: OUT x2 (XLR, RCA), CH OUT x1 (6.3mm Phone), MONITOR x1 (6.3mm Phone)
The frequency characteristics have been newly reviewed to achieve clearer mid-high range and heavier bass.
The channel part of the volume pot Alps RK-27, channel tone controls, and other input/output sections also use Alps pots. In conjunction with the new single CUE specification, a highly durable self-illuminated switch from NKK Switches is adopted. For the signal selection switches, highly durable C&K Switches switches are used for the input selection section and VU meter select switch.
Equipped with CUE and Master mix functions to achieve a more precise mix. The tone control part mounts a volume with a center click that allows you to intuitively know the flat position. The headphone jack part is equipped with an LED light so that you can confirm its location at a glance even in dark locations. The back panel layout has a symmetrical design to eliminate cable clutter in the installation environment. Each channel is equipped with a channel out (post-fader signal) and a separate external input terminal using a standard phone jack so that it can be used to connect external effectors, etc.
